Brand Name : RISE LASER
Model Number : 1064nm
Certification : ISO9001:2008,CE
Place of Origin : Shenzhen
MOQ : 1 PCS
Price : negotiation
Supply Ability : 20000 units
Packaging Details : carton
Product name : laser galvo scanner
Laser type : Co2 Laser
Application : Co2 laser marking machine
Frequency : 1000Hz Servo
Warranty : 3 months
Aperture : 10 mm, 12mm, 16mm
Signal : Digital/analog
CO2 Laser Galvo Head for CO2 Laser Marking Machine Aperture Size 10MM 12MM 16MM Optional
CO2 Laser Galvo Product Description:
| Laser Galvanometer scanner | |||
| E10 | E12 | E16 | |
| Aperture Size | 10mm | 12mm | 16mm |
| Typical Scan Angle | ±20° | ±20° | ±20° |
| Power Requirements | ±15VDC | ±15VDC | ±15VDC |
| 1% Full Scale | 0.36ms | 0.4ms | 0.48ms |
| Marking Speed | 3.5m/s | 3m/s | 2.5m/s |
| Positioning Speed | 7m/s | 6.5m/s | 5.5m/s |
| Writing Speed | 650cps | 600cps | 500cps |
| Repeatability | 10μrad | 10μrad | 10μrad |
| Gain Drift | <80ppm/K | <80ppm/K | <80ppm/K |
| Offset Drift | <50μrad/K | <50μrad/K | <50μrad/K |
| Long-term Drift | 0.3mrad | 0.3mrad | 0.3mrad |
| Operating Temperature | 25℃±10℃ | 25℃±10℃ | 25℃±10℃ |
| Digital Communication | XY2-100 | XY2-100 | XY2-100 |
| Mirror Coatings | YAG/CO2/Silver | YAG/CO2/Silver | YAG/CO2/Silver |
| Weight | 1.38kg | 1.52kg | 2.35kg |
Packaging & Shipping
|  			 Service Time  |  			 			 24 hours waiting for you  |
|  			 Fast Response  |  			 			 2 hours within our worktime,12 hours get off work  |
|  			 Good Service  |  			 			 We can supply you from design, pollishng to coating  |
|  			 MOQ  |  			 			 1 piece, You can mix your order freely  |


|
                                             |

                        Digital Laser Machine Parts Co2 Laser Galvo Scanner 1000Hz 7m / S Positioning Speed Images |
